Features
– Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
– Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
– Supports MAC address auto-learning and auto-aging
– LED indicators for monitoring power, link, activity
– Plastic case, desktop or wall-mounting design
– External power adapter supply
Specifications
– Standards and Protocols:
* IEEE802.3, 802.3u, 802.3ab, 802.3x
* CSMA/CD, TCP/IP
– Basic Function:
* Wire-speed Performance
* MAC Address Auto-Learning and Auto-aging
* IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode
– Backbound Bandwidth: 16Gbps
– MAC Address Table: 4k
– Forwarding Rate:
* 10BASE-T: 14880pps/port
* 100BASE-TX: 148800pps/port
* 1000BASE-T: 1488000pps/port
– Transmission Method: Store-and-Forward
– Ports: 8× 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
– Network Media:
* 10Base-T: UTP category 3, 4, 5 cable (max. 100m)
* EIA/TIA-568 100 STP (max. 100m)
* 100Base-Tx: UTP category 5, 5e cable (max. 100m)
* EIA/TIA-568 100 STP (max. 100m)
* 1000Base-T: UTP category 5, 5e cable (max. 100m)
– LED Indicators: Power, 10/100M, 1000M
– Safety & Emission: FCC, CE
– Dimensions (W×D×H): 200×140×28 mm
– Environment:
* Operating Temperature: 0C – 40C (32F – 104F)
* Storage Temperature: -40C – 70C (-40F – 158F)
* Operating Humidity: 10% – 90% non-condensing
* Storage Humidity: 5% – 90% non-condensing
– Power: External Power Adapter
Jamstvo: 36 mjeseci
Šifra proizvođača: TL-SG1008D
EAN: 6935364092313
