– 24 10/100/1000Mbps ports provide instant large file transfers
– Innovative energy-efficient technology reduces power consumption by up to 40%
– IEEE 802.3x flow control provides reliable data transfers
– 10K Jumbo frame improves performance of large data transfers
– Effective network monitoring via Port Mirroring, Loop Prevention and Cable Diagnostics
– Port and tag-based QoS enable smooth latency-sensitive traffic
– Abundant VLAN features improve network security via traffic segmentation
– IGMP Snooping optimizes multicast applications
– Centrally manage all Easy Smart Switches with Easy Smart Configuration Utility

HARDWARE FEATURES
– Standards and Protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
– Interface:
* 24 10/100/1000Mbps RJ45 Ports
* AUTO Negotiation/AUTO MDI/MDIX
– Network Media:
* 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
* EIA/TIA-568 100Ohm STP (maximum 100m)
* 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
* EIA/TIA-568 100Ohm STP (maximum 100m)
* 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
* EIA/TIA-568 100Ohm STP (maximum 100m)
– Fan Quantity: Fanless
– Power Supply: 100-240VAC, 50/60Hz
– Dimensions (W×D×H): 294×180×44 mm
– Power Consumption: Maximum: 19.2W (220V/50Hz)

PERFORMANCE
– Switching Capacity: 48Gbps
– Packet Forwarding Rate: 35.7Mpps
– MAC Address Table: 8K
– Packet Buffer Memory: 512KB
– Jumbo Frame: 10240Bytes

SOFTWARE FEATURES
– Quality of Service:
* Support Port Based/802.1p Based priority
* Support 4 priority queues
* Rate Limit
* Storm Control
– L2 Features:
* IGMP Snooping
* Link Aggregation
* Port Mirroring
* Cable Diagnostics
* Loop Prevention
– VLAN:
* Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
* MTU/Port/Tag VLAN
– Transmission Method: Store-And-Forward

OTHERS
– System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista Windows 7 or Windows 8, MAC OS, NetWare, UNIX or Linux
– Environment:
* Operating Temperature: 0C – 40C (32F – 104F)
* Storage Temperature: -40C – 70C (-40F – 158F)
* Operating Humidity: 10% – 90% non-condensing
* Storage Humidity: 5% – 90% non-condensing

Jamstvo: 5 godina
Šifra proizvođača: TL-SG1024DE
EAN: 6935364021245
