Specifikacije
– Procesor: Intel LGA1700 (14th / 13th / 12th Gen Core™, Pentium® Gold, Celeron®)
– Čipset: Intel® B760 Express
– Memorija: 4× DDR4 DIMM, do 128 GB, dvokanalna, ECC Un-buffered (radi u non-ECC), non-ECC, XMP
– Brzina memorije: DDR4 2133 – 5333 MT/s (OC)
– Grafika: Integrirana Intel® HD Graphics (ovisno o CPU-u)
– Video izlazi: HDMI 2.1 (4096×2160@60 Hz), 2× DisplayPort 1.2 (4096×2304@60 Hz)
– Podrška za više zaslona: do 4
– Zvuk: Realtek® HD Audio, 2/4/5.1/7.1-kanalni, S/PDIF Out
– Mreža: Realtek® 2.5GbE LAN
– Utori za proširenje: 1× PCIe 4.0 x16 (CPU), 2× PCIe 3.0 x1 (Chipset)
– Pohrana: 2× M.2 (PCIe 4.0 x4/x2), 4× SATA 6 Gb/s
– RAID podrška: RAID 0 / 1 / 5 / 10 (SATA)
– USB priključci: USB Type-C (USB 3.2 Gen 2), USB 3.2 Gen 1, USB 2.0/1.1
– Interni konektori: 24-pin ATX, 8-pin ATX 12V, CPU fan, 3× system fan, RGB i ARGB, 2× M.2, 4× SATA, front panel, audio, USB 3.2 Gen 1, USB 2.0, TPM, serijski i paralelni port, S/PDIF, Q-Flash Plus, reset, Clear CMOS
– Stražnji panel: PS/2, D-Sub, HDMI, 2× DisplayPort, USB Type-C, USB 3.2 Gen 1, USB 2.0, RJ-45, audio priključci
– BIOS: AMI UEFI, 128 Mbit
– Posebne značajke: GIGABYTE Control Center, Q-Flash, Q-Flash Plus, H/W monitoring
– Softver: Norton® Internet Security (OEM), LAN bandwidth management
– Podrška za operativne sustave: Windows 10 / 11 (64-bit)
– Format: Micro ATX (24.4 × 24.4 cm)

Jamstvo: 36 mjeseci
Šifra proizvođača: B760M H DDR4
EAN: 4719331854645
